Product Descriptions
| Datasheet | MID 25KTL3-X1 | MID 30KTL3-X | MID 33KTL3-X | MID 36KTL3-X | MID 40KTL3-X |
| Input data (DC) | |||||
| Max. recommended PV power(for module STC) | 37500W | 45000W | 49500W | 54000W | 60000W |
| Max. DC voltage | 1100V | ||||
| Start Voltage | 250V | ||||
| Normal Voltage | 600V | ||||
| MPPT voltage range | 200-1000V | ||||
| No. of MPP trackers/strings per MPP tracker | 3 | 3 | 3 | 4 | 4 |
| Max.input current per MPP tracker | 26A | ||||
| Max. short-circuit current per MPP tracker | 32A | ||||
| Output data (AC) | |||||
| Rated AC output power | 25000W | 30000W | 33000W | 36000W | 40000W |
| Max. AC apparent power | 27700VA | 33300VA | 36600VA | 39600VA | 44000VA |
| Nominal AC voltage(range*) | 220V/380V, 230V/400V (340-440V) | ||||
| AC grid frequency;(range*) | 50/60 Hz (45-55Hz/55-65 Hz) | ||||
| Max. output current | 40A | 50.5A | 55.5A | 60.0A | 66.6A |
| Adjustable power factor | 0.8 leading – 0.8 lagging | ||||
| THDi | <3% | ||||
| AC grid connection type | 3W+N+PE | ||||
| Efficiency | |||||
| Max.efficiency | 98.8% | ||||
| European efficiency | 98.5% | ||||
| MPPT efficiency | 99.9% | ||||
| General data | |||||
| Dimensions (W / H / D) | 580/435/230mm | ||||
| Weight | 29.5kg | 29.5kg | 29.5kg | 30.5kg | 30.5kg |
| Self-Consumption (night) | < 1W | ||||
| Operating temperature range | –25 °C … +60 °C | ||||
| Topology | Transformerless | ||||
| Cooling | Smart air cooling | ||||
| Protection degree | IP65 | ||||
| Relative Humidity | 0~100% | ||||
| Altitude | 4000m | ||||
| DC connection | H4/MC4(Optional) | ||||
| AC connection | Cable gland+OT terminal | ||||
| Display | OLED+LED/WIFI+APP | ||||
| Interfaces: RS485 / USB /WiFi/ GPRS / RF/ LAN | Yes/Yes /Optional/Optional/Optional/Optional | ||||
| Warranty: 5 years / 10 years | Yes/Optional | ||||
